Range of Travel (mm) |
Pitch of Lead Screw |
Resolution |
Maximum Speed |
| 15 |
1
mm per turn |
0.5 microns (10 Micro-steps per Step Motor Driver in use) |
15 mm / sec |
| 30 |
1
mm per turn |
0.5 microns (10 Micro-steps per Step Motor Driver in use) |
15 mm / sec |
| 50 |
1
mm per turn |
0.5 microns (10 Micro-steps per Step Motor Driver in use) |
15 mm / sec |
| 75 |
1
mm per turn |
0.5 microns (10 Micro-steps per Step Motor Driver in use) |
15 mm / sec |
| 100 |
4
mm per turn
(optional 1 mm per turn) |
2 microns (10 Micro-steps per Step Motor Driver in use) |
50 mm / sec |
| 150 |
4
mm per turn
(optional 1 mm per turn) |
2 microns (10 Micro-steps per Step Motor Driver in use) |
50 mm / sec |
| 200 |
4
mm per turn
(optional 1 mm per turn) |
2 microns (10 Micro-steps per Step Motor Driver in use) |
50 mm / sec |
| 300 |
4
mm per turn
(optional 1 mm per turn) |
2 microns (10 Micro-steps per Step Motor Driver in use) |
50 mm / sec |
| 400 |
5
mm per turn
(optional 1 mm per turn) |
2.5 microns (10 Micro-steps per Step Motor Driver in use) |
50 mm / sec |
| 500 |
5
mm per turn
(optional 1 mm per turn) |
2.5 microns (10 Micro-steps per Step Motor Driver in use) |
50 mm / sec |
| 600 |
5
mm per turn
(optional 1 mm per turn) |
2.5 microns (10 Micro-steps per Step Motor Driver in use) |
50 mm / sec |
| 700 |
5
mm per turn
(optional 1 mm per turn) |
2.5 microns (10 Micro-steps per Step Motor Driver in use) |
50 mm / sec |
| 800 |
5
mm per turn
(optional 1 mm per turn) |
2.5 microns (10 Micro-steps per Step Motor Driver in use) |
50 mm / sec |
| 900 |
5
mm per turn
(optional 1 mm per turn) |
2.5 microns (10 Micro-steps per Step Motor Driver in use) |
50 mm / sec |
| 1000 |
5
mm per turn
(optional 1 mm per turn) |
2.5 microns (10 Micro-steps per Step Motor Driver in use) |
50 mm / sec |
