Stepping,
Voice Coil, DC and Three Phase Brushless Motor Drivers
|
Please use the following comparison table to find the products
that meet your motor driver requirements.
|
SERVO MOTOR DRIVERS |
|
|
Item Number |
Part Number |
Motor Type |
Input Type |
Power Supply Voltage |
Motor Current |
|
|
1 |
 |
SRVODRV-7756 |
DC Servo, Three Phase Brushless |
Step and Direction
Signals, Analog Input |
+20 ~ +80 VDC |
12 Amps Peak
6 Amps Continuous |
|
|
2 |
 |
SRVODRV-8012 |
DC Servo, Three Phase Brushless |
Step and Direction
Signals, Analog Input |
+10 ~ +80 VDC |
20 Amps Peak
12 Amps Continuous |
|
|
3 |
 |
SRVODRV-8020 |
DC Servo |
Step and Direction Signals |
+18 ~ +80 VDC |
0.1 ~ 20 Amps |
|
|
4 |
 |
CLSP-xx |
Solenoid.
Voice Coil Motor |
Step and Direction
or
Phase-A and Phase-B Quadratue Signals
or
0-5
VDC Input Signal
or
4-20 milliamps Input Signal
or
External Potentiometer |
+7.5 ~ +50 VDC |
15 Amps Peak
4 Amps Continuous |
|
|
5 |
|
PWM-05
PWM-06
PWM-07 |
Uni-directional
DC Motor
Fan
Pump |
0-5
VDC Input Signal
or
4-20 milliamps Input Signal
or
External Potentiometer
or
Onboard Potentiometer |
+7.5 ~ +50 VDC |
15 Amps Peak
4 Amps Continuous |
|
|
6 |
 |
DCMD-01 |
Bi-directional
DC Motor
Fan
Pump |
PWM Input |
+6.0 ~ +30 VDC |
15 Amps Peak
4 Amps Continuous |
|
|
7 |
 |
DCMC-01 |
Bi-directional
DC Motor |
User Defined |
+5 ~ +13.5 VDC |
3 Amps Peak
1 Amps Continuous |
|
|
|
|
|
STEPPER MOTOR DRIVERS |
|
|
|
|
Item Number |
Part Number |
Motor Type |
Input Type |
Power Supply Voltage |
Motor Current |
Micro-Stepping Resolution |
|
1 |
 |
STPMDRV-807
|
Stepper |
Step
and Direction Signals |
+24
~ +80 VDC |
1 ~
7 Amps |
10 |
|
2 |
|
STPMDRV-404
|
Stepper |
Step and Direction Signals |
+12 ~ +40 VDC |
0.1 ~ 4 Amps |
2, 4, 5, 8, 10, 16, 25, 32, 50, 64, 125, 128,
250, 256
Jumper Selectable |
|
3 |
|
STPMDRV-243
|
Stepper |
Step and Direction Signals |
+12 ~ +24 VDC |
0.5 ~ 2.5 Amps |
1, 2, 4, 8
Jumper
Selectable |
|
4 |
 |
STPMDRV-504
|
Stepper |
Step and Direction Signals |
+15
~ +50 VDC |
0.1 ~
3.5 Amps |
10 |
|
|
|
|
|
